HTD 3M Closed Loop Timing Belt 231mm – 10mm Wide Synchronous Drive Belt
HTD 3M Closed Loop Timing Belt 231mm – 10mm Wide Synchronous Drive Belt
HTD 3M Closed Loop Timing Belt 231mm – 10mm Wide Synchronous Drive Belt
Zum Zoomen über das Bild scrollen Klicke zum Zoomen auf das Bild
HTD 3M Closed Loop Timing Belt 231mm – 10mm Wide Synchronous Drive BeltHTD 3M Closed Loop Timing Belt 231mm – 10mm Wide Synchronous Drive BeltHTD 3M Closed Loop Timing Belt 231mm – 10mm Wide Synchronous Drive Belt

HTD 3M Closed Loop Timing Belt 231mm – 10mm Wide Synchronous Drive Belt

HomeDIYer
Keine Bewertungen

By HomeDIYer®

Preis:
$2.90 USD
Lagerbestand:
Verfügbar (500 Stück), versandbereit

Payment & Security

Ach Direct Debit Amazon American Express Apple Pay Bancontact Diners Club Discover Google Pay iDEAL Wero Mastercard PayPal Shop Pay USDC Visa

Deine Zahlungsinformationen werden sicher verarbeitet. Wir speichern keine Kreditkartendaten und haben auch keinen Zugang zu deinen Kreditkartendaten.

Quantity Discount Promotion
🎯 BULK DISCOUNT: Buy More, Save More!
Buy 2 Items
5% OFF
Buy 4 Items
10% OFF
Buy 6 Items
15% OFF
✅ Auto-discount • 🔄 Mix & match
Expert

DIY Expert Support

Get fitment advice & recommendations

Mon-Fri, 8:30AM-8PM
WhatsApp WhatsApp Email
⚡
24-Hour Fast Ship
🚚
Arrives in 3-14 days
🌍
Global Reach
↩️
30-Day Returns
🌱 1 tree planted with every purchase

Beschreibung

HTD 3M Closed Loop Timing Belt 231mm — Reliable Synchronous Drive for Precision Machines

When a skipped tooth or a stretched belt throws off your 3D print layer alignment or causes your CNC axis to lose position, the entire job is ruined. Engineers, makers, and repair technicians who rely on precise synchronous motion need a closed loop timing belt that holds its pitch under load — every cycle, every time. This HTD 3M closed loop synchronous timing belt is designed for exactly those demanding applications.

Each order includes 1 piece of a closed loop rubber timing belt with a 231mm (≈9.1") circumference, 10mm (≈3/8") width, and HTD 3M tooth profile (3mm pitch, ≈0.118" between tooth centers). The belt is constructed from neoprene rubber with fiberglass cord reinforcement, providing dimensional stability and resistance to elongation under tension. The molded HTD tooth profile ensures positive engagement with matching 3M pulleys across the full belt width.

This belt is a direct fit for desktop 3D printers using HTD 3M drive systems, small CNC router axis drives, and laser engraver carriage assemblies where a 231mm closed loop synchronous belt is specified. It is also widely used in robotic joint actuators and light-duty automated conveyor systems that require repeatable, slip-free power transmission.

🔗 Compatibility: Fits all HTD 3M pulleys and sprockets. Belt pitch: 3mm. Belt circumference: 231mm. Belt width: 10mm. Not compatible with GT2, T2.5, or MXL pulley profiles.
⚠️ Before ordering: Verify your pulley's tooth profile is HTD 3M and that your drive requires a 231mm circumference belt. If unsure, contact us to confirm compatibility.

✅ Key Features of These HTD 3M Closed Loop Timing Belts

  • 📐Exact 231mm Closed Loop — Seamless closed loop construction with no joint or splice; maintains consistent tension and eliminates the weak point found in cut-to-length belts used in 3D printer axis drives.
  • ⚙️HTD 3M Tooth Profile — Rounded HTD tooth geometry provides deeper pulley engagement than trapezoidal profiles, reducing tooth jump risk in high-torque synchronous drive belt applications.
  • 🧵Fiberglass Cord Reinforcement — Embedded fiberglass tension members resist elongation under cyclic load, keeping axis positioning accurate over thousands of print or cutting cycles.
  • 🌡️Neoprene Rubber Construction — Neoprene body withstands moderate heat, oil mist, and humidity — suitable for enclosed 3D printer chambers and light industrial CNC environments.
  • 📏10mm Working Width — The 10mm (≈3/8") belt width balances compact form factor with adequate load capacity for small CNC router timing belt replacements and robotic actuator drives.
  • 🔄Drop-In Replacement Fit — Dimensionally consistent with OEM HTD 3M-231-10 specifications, making this a straightforward closed loop synchronous belt replacement without pulley modification.

📐 Technical Specifications — HTD 3M Closed Loop Synchronous Timing Belt

Belt Type Closed Loop Synchronous Timing Belt
Tooth Profile HTD 3M (High Torque Drive, 3mm pitch)
Belt Circumference 231mm (≈9.1")
Belt Width 10mm (≈3/8")
Tooth Pitch 3mm (≈0.118")
Number of Teeth 77 teeth (231mm ÷ 3mm)
Body Material Neoprene rubber
Reinforcement Fiberglass cord
Operating Temperature Typically –20°C to +80°C (–4°F to +176°F)
Quantity per Order 1 piece (1 pcs)
Compatible Pulley Profile HTD 3M only
Typical Applications 3D printers, CNC routers, laser engravers, robotics
Color See variant options
Brand HomeDIYer

❓ Frequently Asked Questions

How do I choose the right HTD 3M timing belt length?

Measure the center-to-center distance between your two pulleys, then use the belt length formula: L = 2C + π(D1+D2)/2. This belt has a 231mm (≈9.1") circumference. As a reference, 231mm is approximately 9 and 1/8 inches. When in doubt, check your machine's parts list or contact us to confirm before ordering.

What pitch is this timing belt, and what pulleys does it fit?

This is an HTD 3M pitch belt — 3mm (≈0.118") between tooth centers with a rounded HTD tooth profile. It fits any HTD 3M pulley or sprocket. It is not compatible with GT2 (2mm pitch), T2.5, MXL, or other tooth profiles, even if the belt width matches.

What load or torque can this belt handle?

HTD 3M belts at 10mm width are generally suited for light-to-medium duty synchronous drives. Typical tensile load capacity is in the range of 100–300 N depending on operating speed, pulley diameter, and wrap angle. For heavier loads, consider a wider belt (15mm or 20mm) or a larger pitch such as HTD 5M.

Can this belt be used outdoors or in wet/oily environments?

Neoprene rubber timing belts are generally resistant to moderate moisture, oil mist, and temperature variation. They are typically rated for –20°C to +80°C (–4°F to +176°F). They are not recommended for continuous submersion, exposure to strong solvents, or prolonged UV radiation without shielding.

Is this belt compatible with GT2 or other common 3D printer belt profiles?

No. HTD 3M and GT2 are different tooth profiles and are not interchangeable. GT2 has a 2mm pitch with a different tooth geometry. Always verify your printer or machine specifies HTD 3M before ordering. Common machines using HTD 3M include certain Creality, Prusa, and industrial-grade motion systems — check your BOM or service manual.

How many belts are included, and can I order multiple?

Each order includes 1 piece of the HTD 3M-231-10 closed loop timing belt. To order multiple belts, simply increase the quantity in your cart before checkout. Bulk pricing may be available — contact us for volume orders.

What machines commonly use the HTD 3M 231mm belt size?

The 231mm circumference HTD 3M belt is commonly found in desktop 3D printers, small CNC routers, laser engravers, robotic arm joints, and light-duty automated conveyor systems. It is a frequently specified closed loop synchronous belt replacement part for machines requiring precise, slip-free axis motion.
