LED Illuminated Toggle Switch — Waterproof ON/OFF Control for Panels & Dashboards

When a plain unlabeled switch just isn't enough — when you need to know at a glance whether a circuit is live — a LED illuminated toggle switch solves the problem instantly. Electricians, hobbyists, marine installers, and automotive builders rely on illuminated panel switches to eliminate guesswork on busy control boards.

Each switch ships as a single unit with the toggle lever, integrated LED indicator, mounting nut, and sealing washer included. Available in two panel cutout sizes — 16mm (≈5/8") and 19mm (≈3/4") — with LED colors in Red, Blue, or Green. Voltage options cover both low-voltage DC systems (5–24V) and standard AC mains (220V). The switch is rated at 7A / 250VAC.

Typical applications include 12V automotive and RV dashboard panels, marine vessel control consoles, industrial machine control enclosures, DIY electronics projects requiring a waterproof on/off toggle switch with indicator light, and outdoor power distribution boxes.

🔌 Compatibility: Fits standard 16mm or 19mm round panel cutouts. Choose 5-24V for DC/low-voltage systems (automotive, RV, marine, Arduino) or 220V for AC mains panels. Verify your panel thickness and cutout diameter before ordering.

✅ Key Features of These LED Illuminated Waterproof Toggle Switches

💡Built-In LED Indicator — The integrated LED lights up when the switch is ON, giving you instant visual confirmation of circuit status — no separate pilot light needed.
🎨Three LED Color Options — Choose Red, Blue, or Green to match your panel design or follow industry color conventions for power, run, and stop functions.
📐Two Mounting Sizes — Available in 16mm (≈5/8") and 19mm (≈3/4") panel cutout diameters, covering the most common chassis punch and step-drill sizes used in control panel builds.
⚡Wide Voltage Range — The 5-24V variant suits 12V/24V DC systems; the 220V variant handles standard AC mains. One switch design, two voltage worlds.
💧Waterproof Sealing Ring — A rubber gasket around the mounting thread seals against moisture ingress, making this switch suitable for outdoor enclosures, marine dashboards, and wash-down environments.
🔩Secure Panel Mount Design — The threaded bushing and locking nut hold the switch firmly in place even under vibration, a key requirement for automotive and marine waterproof toggle switch installations.

📐 Technical Specifications — LED Illuminated Panel Toggle Switch

Switch Type	SPST ON/OFF 2-Position Toggle
Panel Cutout Size	16mm (≈5/8") or 19mm (≈3/4") — see variant options
Current Rating	7A
Voltage Rating (AC)	250VAC
LED Indicator Voltage	5–24V DC (low-voltage variant) or 220V AC (mains variant)
LED Colors Available	Red, Blue, Green
Waterproof Rating	Sealed mounting gasket — suitable for splash/outdoor use
Mounting Method	Threaded bushing with locking nut
Terminal Type	Solder / quick-connect tabs — see variant options
Body Material	Typically ABS plastic housing with metal bushing
Operating Temperature	Generally –20°C to +85°C (–4°F to +185°F)
Quantity per Order	1 piece (single switch)

⚠️ Note: For AC mains (220V) wiring, always follow local electrical codes and ensure power is off before installation. If you are unsure of your panel cutout size, measure the existing hole diameter or check your chassis punch size before selecting a variant.

❓ Frequently Asked Questions

What panel cutout size do I need for this toggle switch?

This switch is available in two mounting hole sizes: 16mm (≈5/8" / 0.63") and 19mm (≈3/4" / 0.75"). Measure your existing panel cutout diameter before ordering. If you are drilling a new hole, use a step drill bit or chassis punch sized to match. When in doubt, 16mm is the more common size for compact panels; 19mm is standard for larger industrial enclosures.

What current and voltage can this toggle switch handle?

The switch is rated at 7A at 250VAC. For DC circuits, it is generally suitable for loads up to 7A at 12V or 24V. Always protect your circuit with a fuse or breaker sized to the load — not the switch maximum rating. Avoid using this switch for motor inrush loads that significantly exceed the rated current.

Is this toggle switch waterproof for outdoor or marine use?

Yes. A rubber sealing gasket around the mounting thread protects against moisture ingress from the front face of the panel, making it suitable for outdoor enclosures, marine dashboards, RV exteriors, and wash-down environments. For fully submerged or high-pressure wash applications, additional sealing of the wiring terminals is recommended.

Which LED voltage option should I choose — 5-24V or 220V?

Choose 5-24V for low-voltage DC systems: 12V automotive, marine, RV, camper van builds, Arduino/Raspberry Pi projects, or any 5V–24V control panel. Choose 220V for standard household or industrial AC mains circuits (typically 110V–240V). The LED indicator draws power directly from the switched circuit, so matching the voltage variant to your system is essential.

What LED colors are available and how do I choose?

Red, Blue, and Green LED options are available. The LED illuminates when the switch is in the ON position. Color choice is generally a matter of panel aesthetics or convention — Green is commonly used for "running" or "power on" status, Red for "stop" or "caution" circuits, and Blue for auxiliary or accent lighting on custom builds.

How do I wire this LED toggle switch?

This is typically an SPST (Single Pole Single Throw) ON/OFF switch with an integrated LED. It generally has 3 terminals: two for the main switched circuit (COM and load) and one for the LED return (ground or neutral). Terminal markings are printed on the switch body. For AC mains wiring, always turn off power at the breaker and follow local electrical codes before installation.

Can I use this switch in an automotive or RV application?

Yes — the 5-24V variant is well-suited for 12V automotive, RV, boat, off-road vehicle, and camper van control panels. The waterproof gasket, compact 16mm or 19mm footprint, and secure locking nut make it a practical choice for dashboard and console builds where vibration resistance and moisture protection matter.

🛒 Select your size and LED color above, then add to cart — ships from our US warehouse.
