Mini Slide Switch SPDT 2/3-Position — Reliable PCB Micro Toggle for Electronics Projects

When your circuit needs a dependable, space-saving way to switch between states, a loose or mismatched toggle can derail an entire build. Makers, engineers, and electronics hobbyists who work with compact PCBs know the frustration of hunting for the right mini slide switch — one that fits the footprint, matches the pin count, and actually stays in stock. This assortment of PCB mini slide switches covers the most common configurations used in DIY electronics, prototyping, and small-appliance repair.

Each set includes your chosen switch model — available in configurations such as the SS-12D00, SS-12D10, MSK12D19, SS-12D07, MSK-12C01, SS-12F15, SS-12F44, MSS22D18, SK12F14, SS-23F19, SS12F23, SS22L05, SS-13D07, SK-13D07, MSK22D18, and SS-22D07 — spanning 3-pin, 4-pin, and 6-pin layouts with 2-position (SPDT) or 3-position switching action. Quantities per set range from 1 piece to 20 pieces depending on the model, and you can order 1 set up to 55 sets for prototyping or production runs. These switches are constructed with a plastic housing and metal contact mechanism, sized for through-hole PCB mounting with pin spacing typically in the 2.54mm (0.1″) range.

Typical use cases include mode selection switches in Arduino and Raspberry Pi projects, power routing in DIY audio equipment, channel switching in model railway control panels, and signal path selection in test and measurement instruments. Whether you need a single-pole mini slide switch for a breadboard prototype or a double-pole 6-pin slide switch for a dual-channel audio circuit, this listing covers the configurations most frequently searched by US electronics builders.

🔌 Compatibility Note: These are through-hole PCB-mount slide switches. Pin spacing is typically 2.54mm (0.1″) — confirm your PCB footprint dimensions against the specific model datasheet before ordering. Not designed for panel-mount or surface-mount (SMD) applications.

✅ Key Features of These Mini Slide Switches

🔀2-Position & 3-Position Options — Choose SPDT 2-position for simple on/off or on/on switching, or 3-position for center-off and dual-circuit control — both configurations available across multiple models in this listing.
📌3, 4, and 6 Pin Configurations — Single-pole 3-pin switches for basic signal routing, 4-pin variants for grounded layouts, and 6-pin double-pole switches for simultaneous dual-circuit switching in audio and power applications.
🧩PCB Through-Hole Mount Design — Compact footprint engineered for direct PCB soldering; pin spacing generally follows the 2.54mm (0.1″) standard used in most maker and prototyping boards.
📦Flexible Quantity Sets — Order from 1 set to 55 sets to match your project scale — whether you need a single switch for a one-off repair or bulk quantities for a production run or classroom kit.
⚙️Broad Model Coverage — 17 switch models in one listing, including SS-12 series, MSK-12 series, SS-22 series, and SS-13 series, covering the most common mini slide switch footprints used in consumer electronics and DIY builds.
🚂Suitable for Model Railway & Hobby Control Panels — The compact actuator travel and stable detent action make these micro toggle switches a practical choice for model railway layout control, RC electronics, and hobby instrument panels.

📐 Technical Specifications — Mini PCB Slide Switch

Switch Type	Miniature PCB slide switch (micro toggle)
Positions	2-position (SPDT) or 3-position — see variant options
Pin Count	3 pin, 4 pin, or 6 pin — see variant options
Models Available	SS-12D00, SS-12D10, MSK12D19, SS-12D07, MSK-12C01 (3-pin & 7-pin), SS-12F15, SS-12F44, MSS22D18, SK12F14, SS-23F19, SS12F23, SS22L05, SS-13D07, SK-13D07, MSK22D18, SS-22D07
Mounting Type	Through-hole PCB mount
Pin Spacing	Typically 2.54mm (0.1″) — confirm per model datasheet
Rated Current	Typically 0.3A–0.5A (signal-level; confirm per model)
Rated Voltage	Typically 6V DC (low-power signal use; confirm per model)
Housing Material	Plastic body with metal contact mechanism
Actuator Travel	See variant options / Contact us to confirm
Quantity per Set	1 pc to 20 pcs per set depending on model — see variant options
Sets per Order	1 set, 4 sets, 5 sets, 10 sets, 24 sets, 40 sets, or 55 sets
Application	PCB prototyping, Arduino/Raspberry Pi projects, model railway, audio switching, hobby electronics

⚠️ Spec Confirmation: Electrical ratings (current, voltage, actuator travel) vary by model. Always cross-reference the specific model number against its datasheet before use in safety-critical or high-current applications.

❓ Frequently Asked Questions

How do I choose the right mini slide switch size for my project?

Match the switch to your PCB footprint and circuit requirements. 2-position (SPDT) switches are generally used for simple on/off control, while 3-position switches suit applications needing a center-off or dual-circuit state. Check the pin count (3, 4, or 6 pins) against your schematic. When in doubt, measure the mounting hole spacing on your board before ordering — pin spacing is typically 2.54mm (0.1″) for most models in this series.

What current and voltage ratings do these PCB slide switches typically handle?

Miniature PCB slide switches in this class typically handle 0.3A–0.5A at 6V DC in low-power signal applications. They are generally not rated for mains voltage or high-current loads. Always verify the datasheet for the specific model (e.g., SS-12D00, MSK12D19) before use in your circuit.

Are these slide switches suitable for outdoor or high-humidity environments?

These are standard PCB-mount slide switches without an IP-rated enclosure, so they are generally intended for indoor or enclosed electronics use. For outdoor or high-humidity environments, consider housing the PCB in a sealed enclosure to protect the switch contacts from moisture and corrosion.

What is the difference between 2-position and 3-position slide switches?

A 2-position switch toggles between two states (e.g., ON-ON or ON-OFF). A 3-position switch adds a center state, commonly used for ON-OFF-ON configurations, allowing you to switch between two circuits or include a neutral/off position in the middle. The SS-13D07 and SS-23F19 models in this listing are 3-position variants.

Are these switches compatible with standard 2.54mm (0.1″) pitch PCB layouts?

Most miniature slide switches in the SS-12 and MSK-12 series are designed for standard 2.54mm (0.1″) pitch PCB through-hole mounting. However, pin spacing can vary by model. We recommend confirming the datasheet dimensions for your specific switch model before finalizing your PCB layout.

How do I decide between 3-pin, 4-pin, and 6-pin slide switches?

3-pin switches are typically single-pole (SPDT or SPST), suitable for routing one signal path. 4-pin switches generally add a ground or second pole. 6-pin switches are commonly double-pole (DPDT), allowing simultaneous switching of two independent circuits — useful in audio, power routing, or dual-channel control applications. Models like MSS22D18, SS-22D07, and MSK22D18 are 6-pin variants in this listing.

Can I use these switches for Arduino, Raspberry Pi, or other maker projects?

Yes. These mini slide switches are widely used in maker and hobbyist electronics, including Arduino and Raspberry Pi projects, for mode selection, power control, and signal routing. Their compact footprint makes them well-suited for breadboard prototyping and custom PCB designs. The 3-pin 2-position models are the most common choice for simple GPIO-level switching.
