Miniature Slide Toggle Switch — 2/3-Position, Single/Double Row, Vertical & Horizontal, Through-Hole & SMD

Zum Zoomen über das Bild scrollen Klicke zum Zoomen auf das Bild

Miniature Slide Toggle Switch — 2/3-Position, Single/Double Row, Vertical & Horizontal, Through-Hole & SMD

HomeDIYer

Keine Bewertungen

By HomeDIYer®

Size: SS-12F44 2-way 3-pin vertical

Packing Quantity: 15 pcs

Preis:

$1.35 USD

Lagerbestand:

Verfügbar (500 Stück), versandbereit

Menge:

Teile dieses Produkt

Deine Zahlungsinformationen werden sicher verarbeitet. Wir speichern keine Kreditkartendaten und haben auch keinen Zugang zu deinen Kreditkartendaten.

Quantity Discount Promotion

DIY Expert Support

Get fitment advice & recommendations

Mon-Fri, 8:30AM-8PM

WhatsApp Email

⚡

24-Hour Fast Ship

🚚

Arrives in 3-14 days

🌍

Global Reach

↩️

30-Day Returns

🌱 1 tree planted with every purchase

Miniature Slide Toggle Switch — Reliable 2/3-Position PCB Switching for DIY Electronics

When your PCB layout demands a compact, reliable switching solution, a poorly chosen switch can mean rework, signal noise, or a board that simply won't fit in its enclosure. Engineers, hobbyists, and electronics makers who need a miniature slide toggle switch that drops cleanly into tight footprints — whether through-hole vertical, horizontal, or SMD — will find this series covers the full range of common configurations.

Each variant in this listing is a single miniature slide toggle switch from the SS, SK, MSS, or MSK series, available in 2-position (SPDT / 1P2T) and 3-position (SP3T) configurations with 3, 4, 6, 7, or 8 pins depending on the model. Mounting styles include vertical through-hole, horizontal through-hole, and SMD surface-mount. Packing quantities range from 2 pcs to 3,000 pcs per order, making this listing suitable for both prototyping and small-batch production runs.

Typical use cases include mode-selection switches on Arduino and Raspberry Pi boards, power-path routing on custom PCBs, channel-select switches in audio and RF circuits, and configuration jumper replacements in embedded systems where a user-accessible slide switch for PCB projects is preferred over a jumper block.

🔌 Compatibility Note: These switches are designed for low-voltage PCB signal applications (typically 6V–12V DC, 0.3A–0.5A). Verify pin pitch and footprint against your PCB design before ordering. SMD and through-hole variants are not interchangeable on the same footprint.

⚠️ Spec Confirmation: Exact pin pitch, actuator height, and current rating vary by model. If your design has tight tolerances, contact us with your model number to confirm specifications before placing a bulk order.

✅ Key Features of These Miniature Slide Toggle Switches

📐Multiple Mounting Styles — Vertical through-hole, horizontal through-hole, and SMD variants available in a single listing, so you can source the right miniature slide switch for PCB mounting without switching suppliers.
🔀2-Position & 3-Position Configurations — SPDT (1P2T) 2-way and SP3T 3-way options cover signal routing, mode selection, and channel switching in one product family.
📦Flexible Packing Quantities — Order from 2 pcs for prototyping up to 3,000 pcs for production runs, with tiered pricing that scales down per-unit cost as quantity increases.
🔩Single & Double Row Pin Layouts — Single-row 3-pin and 4-pin models for compact footprints; double-row 6-pin and 8-pin models for double-pole or higher-density switching on tight PCB layouts.
⚡Low-Profile Actuator Design — The slide actuator sits close to the PCB surface, making these switches well-suited for low-clearance enclosures and panel-mount cutouts in DIY electronics enclosures.
🛠️Maker & Production Ready — Compatible with standard PCB assembly workflows; SMD variants are pick-and-place friendly, while through-hole models are easy to hand-solder for Arduino slide switch projects and custom builds.

📐 Technical Specifications — Miniature Slide Toggle Switch Series

Product Type	Miniature Slide Toggle Switch (SS / SK / MSS / MSK Series)
Switch Positions	2-position (SPDT / 1P2T) or 3-position (SP3T) — see variant options
Pin Count	3-pin, 4-pin, 6-pin, 7-pin, or 8-pin — see variant options
Row Configuration	Single row or double row — see variant options
Mounting Style	Vertical through-hole, horizontal through-hole, or SMD — see variant options
Pin Pitch	Typically 1.5mm–2.54mm depending on model; contact us to confirm
Rated Voltage	Typically 6V–12V DC (signal-level use); contact us to confirm per model
Rated Current	Typically 0.3A–0.5A; contact us to confirm per model
Mechanical Life	Typically 5,000–10,000 cycles
Actuator Type	Slide (linear actuator)
Body Material	Thermoplastic housing, copper alloy contacts
Operating Temperature	Typically -20°C to +70°C (–4°F to +158°F)
Packing Quantity	2 / 5 / 10 / 15 / 20 / 30 / 50 / 100 / 150 / 200 / 300 / 500 / 1000 / 1500 / 2000 / 3000 pcs
Country of Origin	See variant options

❓ Frequently Asked Questions

How do I choose the right switch model for my project?

Start with your circuit requirement: 2-position (SPDT/1P2T) for simple on/off or signal routing, 3-position (SP3T) for three-state selection. Then match the pin count to your PCB footprint — 3-pin for single-pole, 6-pin for double-pole, 8-pin for triple-pole or double-row configurations. Finally, choose vertical (through-hole), horizontal, or SMD mounting based on your board layout and enclosure clearance.

What is the difference between SS, SK, MSS, and MSK series?

SS and SK series are generally standard through-hole slide switches with vertical or horizontal orientation. MSS and MSK series typically feature a micro or miniaturized form factor, often with SMD variants available. All series in this listing share the same basic slide-actuator mechanism and are compatible with standard PCB design rules. Contact us with your specific model number if you need dimensional drawings.

What current and voltage ratings do these switches support?

Miniature slide switches of this type typically support 0.3A–0.5A at 6V DC for signal-level applications. Some models may support up to 100mA at 12V DC. These are low-power signal switches — they are not rated for mains voltage or high-current loads. Always confirm the exact rating for your chosen model before use in safety-critical circuits.

Are these switches suitable for outdoor or high-humidity environments?

These miniature slide switches are generally designed for indoor PCB use in controlled environments. They are not rated for outdoor exposure, moisture ingress, or high-humidity conditions without additional conformal coating or enclosure protection. For outdoor or harsh-environment applications, consider adding a sealed enclosure around the PCB assembly.

What PCB footprint or pin pitch do these switches use?

Pin pitch for miniature slide switches in this series is typically 1.5mm–2.54mm depending on the model. SMD variants follow standard SMD land patterns. Please refer to the specific model datasheet or contact us to confirm the exact footprint before finalizing your PCB layout — especially for production runs.

Can I use these switches for Arduino, Raspberry Pi, or other maker projects?

Yes. These miniature slide switches are widely used in DIY electronics, Arduino projects, Raspberry Pi HATs, and custom PCB builds. The 3-pin SPDT variants are especially popular for signal routing and mode selection in maker projects. Ensure your logic voltage (3.3V or 5V) is within the switch's rated range, and verify the pin pitch matches your breadboard or PCB holes.

What is the mechanical lifespan of these switches?

Miniature slide switches of this type generally have a rated mechanical life of 5,000–10,000 cycles under normal operating conditions. Actual lifespan depends on actuation force, frequency of use, and environmental conditions. For high-cycle applications, contact us to confirm the specific model's rated cycle count before committing to a production design.

🛒 Select your size and packing quantity above, then add to cart — ships from our US warehouse.
