When a mismatched or worn sprocket causes chain skip, vibration, or premature wear on your small-pitch drivetrain, the fix starts with a dimensionally accurate replacement. These 04C roller chain sprockets are engineered for makers, hobbyists, and light-industrial builders who need reliable 1/4" chain drive performance in compact assemblies — from go-karts and mini bikes to conveyor systems and robotic platforms.
Each sprocket is machined from 45 carbon steel and finished with a blackening treatment that provides a uniform matte surface and baseline corrosion resistance. The tooth count range spans 10T through 23T, with bore options from 5mm to 16mm (approximately 0.197" to 0.630") to suit a wide variety of shaft diameters. The pitch is 6.35mm (1/4"), conforming to the 04C chain standard, and the M5 threaded set-screw hole allows secure shaft locking without additional hardware.
Typical use cases include go-kart and mini-moto final drive reduction, small conveyor belt drive systems requiring precise speed ratios, and DIY robotics or automation rigs where a compact 1/4" chain loop is preferred over belt or gear drive. The wide tooth-count selection makes it straightforward to dial in your target gear ratio without custom machining.
Choose from 14 tooth counts to achieve your exact gear ratio without custom machining. Covers common reduction and overdrive configurations for go-karts, conveyors, and robotics.
Tooth profile machined to 04C chain standard for smooth engagement, reduced noise, and even load distribution across every link in the chain loop.
Available with bore diameters from 5mm to 16mm to fit a broad range of motor and axle shaft sizes. Select your exact bore from the variant dropdown above.
45 steel provides solid tensile strength and wear resistance for light-to-medium duty applications. The blackening finish adds a uniform surface treatment and baseline oxidation resistance.
Integrated M5 threaded set-screw hole allows the sprocket to be locked firmly onto the shaft without additional collars or adapters, simplifying installation in tight spaces.
Dimensionally consistent with standard 04C sprocket specifications, making these a direct swap for worn or damaged sprockets on existing 1/4" chain drive assemblies.
| Chain Standard | 04C (1/4" Roller Chain) |
|---|---|
| Chain Pitch | 6.35mm (0.250") |
| Tooth Count Range | 10T – 23T |
| Bore Diameter Range | 5mm – 16mm (0.197" – 0.630") |
| Set-Screw Thread | M5 |
| Material | 45 Carbon Steel |
| Surface Finish | Blackening Treatment |
| Outer Diameter | See variant options |
| Hub Diameter | See variant options |
| Hub Length | See variant options |
| Weight | See variant options |
| Quantity per Order | 1 piece |
This sprocket is designed for 04C roller chain, also referred to as 1/4" roller chain, with a pitch of 6.35mm. It will not fit 25H, 35, 40, or other chain standards. Always confirm your chain pitch before ordering.
Measure your motor or axle shaft diameter with a caliper. Select the bore option that matches your shaft exactly — available sizes range from 5mm to 16mm. The M5 set screw locks the sprocket onto the shaft, so a snug fit is important for concentricity and torque transfer.
Divide the driver sprocket tooth count by the driven sprocket tooth count to get your reduction ratio. For example, a 10T driver paired with a 20T driven sprocket gives a 2:1 reduction. Choose from 10T through 23T to achieve your target ratio without custom parts.
45 carbon steel is a medium-carbon structural steel with good tensile strength and wear resistance, suitable for light-to-medium duty drivetrain applications such as go-karts, mini bikes, and small conveyors. For high-shock or continuous heavy-load applications, consider upgrading to a hardened alloy sprocket.
The blackening treatment provides a baseline level of oxidation resistance and a uniform matte appearance. For outdoor or high-humidity environments, we recommend applying a light coat of chain lubricant or anti-rust spray to maintain the finish and extend service life.
These sprockets use an M5 set-screw locking mechanism and do not include a keyway slot. If your shaft requires a keyed connection, you would need to have a keyway machined into the bore by a local machine shop, or select a sprocket that comes pre-machined with a keyway.
Both 04C and 25H chains share a 6.35mm pitch, but they differ in roller diameter and inner link width. 04C follows the ISO/DIN metric standard while 25H follows the ANSI standard. These sprockets are designed for 04C chain — using them with 25H chain may result in poor engagement and accelerated wear. Always match sprocket and chain standards.
