Most fastener listings cover M3 to M8. Finding the right stainless pan head screw at M1.0, M1.2, M1.4, or M1.6 — or needing M10 at 200mm — usually means searching multiple suppliers. These A2 (304) stainless steel Phillips and Pozi pan head machine screws cover the complete range from M1.0 through M10 in a single listing, with over 240 size combinations from M1.0×3mm (0.12”) to M10×60mm (2.36”) and lengths up to 200mm (7.87”) on M5 and M6.
The pan head profile provides a wide, flat bearing surface that distributes clamping force evenly across panels, PCB surfaces, and housings. The Phillips/Pozi drive is compatible with standard screwdrivers from PH000 (M1 micro) to PH3 (M10 structural). All sizes are sold in packs of 5 pieces — ideal for exact replacements, prototyping, and small-batch production.
Typical applications span the full range: watch, eyeglass, and precision instrument repair (M1.0–M1.6), PCB and electronics assembly (M2–M3), electronics enclosures and panel mounting (M3–M5), general-purpose DIY and workshop projects (M4–M6), and medium structural fastening in machinery and equipment (M6–M10).
| Material | A2 Stainless Steel (304 / 18-8) |
|---|---|
| Finish | Natural stainless (no coating) |
| Thread Standard | ISO Metric |
| Thread Diameters | M1.0, M1.2, M1.4, M1.6, M2, M2.5, M3, M3.5, M4, M5, M6, M8, M10 |
| Head Style | Pan Head (Round Head) |
| Drive Type | Phillips / Pozi (Pozidriv) — PH000/PZ000 to PH3/PZ3 |
| Length Range (M1.0) | 3mm (0.12”) to 5mm (0.20”) |
| Length Range (M1.2) | 3mm (0.12”) to 6mm (0.24”) |
| Length Range (M1.4) | 3mm (0.12”) to 12mm (0.47”) |
| Length Range (M1.6) | 3mm (0.12”) to 16mm (0.63”) |
| Length Range (M2) | 2mm (0.08”) to 60mm (2.36”) |
| Length Range (M2.5) | 3mm (0.12”) to 60mm (2.36”) |
| Length Range (M3) | 3mm (0.12”) to 120mm (4.72”) |
| Length Range (M3.5) | 6mm (0.24”) to 60mm (2.36”) |
| Length Range (M4) | 4mm (0.16”) to 180mm (7.09”) |
| Length Range (M5) | 6mm (0.24”) to 200mm (7.87”) |
| Length Range (M6) | 6mm (0.24”) to 200mm (7.87”) |
| Length Range (M8) | 10mm (0.39”) to 100mm (3.94”) |
| Length Range (M10) | 16mm (0.63”) to 60mm (2.36”) |
| Pack Size | 5 pcs (all sizes) |
| Screw Type | Machine screw (requires tapped hole or nut) |
| Length Measurement | Excluding head (shaft length only) |
| Corrosion Resistance | Excellent — suitable for indoor and light outdoor use |
| Common Applications | Watches, eyeglasses, precision instruments (M1–M1.6), PCB & electronics (M2–M3), enclosures & panels (M3–M5), DIY & machinery (M4–M10) |
Phillips has a simple cross-shaped drive. Pozi (Pozidriv) adds a second set of grooves at 45°, providing better torque transfer and significantly reduced cam-out. A Pozi driver is recommended for best results; a standard Phillips driver will also engage these screws. For M1–M2 micro sizes, use a precision driver and apply minimal torque.
Phillips or Pozi screwdriver matched to the screw size: PH000/PZ000 for M1–M1.4, PH00/PZ00 for M1.6–M2, PH0/PZ0 for M2.5–M3, PH1/PZ1 for M3.5–M4, PH2/PZ2 for M5–M6, PH3/PZ3 for M8–M10. Always use a well-fitting driver to avoid cam-out, especially on smaller sizes.
Measure the depth of the tapped hole or the thickness of the material being clamped. The screw length (excluding head) should engage at least 1.5× the thread diameter. Available lengths: 3mm (0.12”) to 200mm (7.87”) depending on the diameter. Not all lengths are available for every diameter — check the Size selector. When in doubt, size up.
A2 is the most common grade of austenitic stainless steel, equivalent to 304 or 18-8 stainless. It offers excellent corrosion resistance, is non-magnetic in most conditions, and is the standard material for general-purpose stainless fasteners in electronics, appliances, and light outdoor use.
Yes. M1.0, M1.2, M1.4, and M1.6 are standard micro fastener sizes used in watches, eyeglasses, cameras, and precision instruments. A precision screwdriver set (PH000/PH00) and careful torque control are essential at these sizes — do not overtighten.
A2 stainless steel provides strong corrosion resistance and will not rust under normal indoor conditions or light outdoor exposure. For marine, coastal, or highly corrosive environments, A4 (316) stainless is generally recommended.
Yes — these are machine screws, not self-tapping. They require a pre-tapped M-series hole or a matching metric nut in the same thread size. They will not cut their own thread into plastic or metal.
All sizes are sold in packs of 5 pieces. This makes it easy to order exactly what you need for a repair, prototype, or small-batch production without over-ordering. Select your preferred thread diameter and length using the Size option above.
