| Product Type | Single Box Universal Seat Suspension Kit (with Slider) |
| Color | Black (Powder Coated) |
| Material | Q235 Structural Steel, 65Mn Spring Steel |
| Steel Thickness | 3mm (0.12 inch) main frame |
| Assembled Dimensions (L×W×H) | 20.08" × 14.57" × 5.12" (510 × 370 × 130 mm) |
| Product Weight | 23.22 lbs (10.54 kg) |
| Package Dimensions (L×W×H) | 20.08" × 14.57" × 5.12" |
| Package Weight | 23.32 lbs (10.58 kg) |
| Weight Capacity | 50–130 kg (110–286 lbs) — optimized for most operators |
| Shock Absorption Travel | 30mm (1.18") |
| Slider Adjustment Range | 150mm (6 inches) forward/backward |
| Extension Wire Length | 50 cm (19.7 inches) |
| Mounting Compatibility | 8 additional mounting holes; fits lawn mowers, tractors, forklifts, dozers |
✅ Yes, highly likely. This is a universal kit designed with a broad mounting pattern plus 8 auxiliary holes. It fits most residential and commercial lawn tractors, zero‑turns, forklifts, and compact utility vehicles. The bolt spacing accommodates common OEM and aftermarket seats. If you have an unusual bolt pattern, the extra slots usually allow a bolt‑on fit. Please measure your existing mounting holes (typical width around 11"–13") and compare to our 14.57" overall width — the slider base provides plenty of adjustment.
💪 Absolutely. The suspension is tuned for operators between 50 kg and 130 kg (110–286 lbs). At 240 lbs, you're right in the sweet spot. The 65Mn springs and 3mm steel frame are overbuilt for commercial use. You'll experience the full 1.18" of travel, and the slider remains smooth even under heavier loads.
🔄 The slider is built‑in! This is a complete suspension + slider assembly. The slider mechanism allows 6 inches of fore/aft adjustment and is pre‑installed on the suspension base. You simply bolt your existing seat to the top slider tracks and mount the base to your machine. No extra purchases needed.
🛠️ Basic mechanical skills are sufficient. You'll need standard wrenches/sockets (typically 13mm–17mm) and possibly a drill if you need to enlarge a hole — though in most cases it's a direct bolt‑on. The included 19.7" switch extension wire makes connecting safety switches straightforward. Most users complete the swap in under 45 minutes. We recommend checking the mounting template before final tightening.
📐 Minimal height increase. The assembled height is 5.12 inches (from base to top of slider). When replacing a worn‑out fixed mount, the overall seat height might increase by 1–2 inches, depending on your original setup. Most operators appreciate the slight boost in visibility and legroom. If you're concerned about headroom, you can often adjust the slider to find a comfortable position.
